300-400 RPM Universal Used Circular Loom Machine For Woven Bags

Certification : CE ISO

Place of Origin : China

MOQ : 1 set

Price : negotiate

Payment Terms : L/C, T/T

Supply Ability : 10 sets/month

Delivery Time : 15 days

Packaging Details : Wooden Case

Winding Motor Power : 10kgs Torque Motor

Normal Rating of Main Motor : 2.2kw

Weft Density : 10-24PCS/10cm

Working Width : 60-750mm

Maximum Weaving Speed : 300-400 RPM

Power Consumption : 5-7 kW

Additional Features : Automatic stop motion, electronic control system

Condition : Used

Contact Now

Universal Intelligent Used Circular Loom Machine For Wooven Bags

Descripition:
Mesh bag circular loom is mainly used to produce cylindrical mesh bags for packaging vegetables, fruits and other agricultural products. The suitable raw material is PE or PP. 100% recycled materials can be used also. Usually weft yarn is flat yarn(tape) and warp yarn can be monofilament or flat yarn.

Advantages:
1. The structure design of the whole machine is novel and reasonable, the maintenance is convenient.
2. High speed, low noise , low friction, energy saving , high efficiency.
3. Adopting the interweaving technology, the weft is not easy to loosen, and it is not easy to stretch after filling with fruits and vegetables.
4. The loom is controlled by Inverter, and it will automatically stop if the weft are finished or the warp, weft yarn is cut off, machine also equip with a meter counter.
5. Intelligent system is used for lifting and winding of fabric, automatic tracking and synchronization.

Main technical Datas:

Working width,double flat	60-750mm
Number of shuttles per machine	4
weft density	10-24pcs/10cm
Speed	0-120RPM
Warp feeding	Motor
Inner diameter of Bobbin	38mm
Bobbin length	230mm
Max. bobbin diameter	100mm
Number of Warp yarns	512pcs
Normal rating of main motor	2.2kw
lift motor power :	22N
winding motor power:	10kgs Torque motor
Total power	3Kw
Installed size (mm)	10500* 2400* 3200
weight	2T

Machine Photos:

300-400 RPM Universal Used Circular Loom Machine For Woven Bags

FAQ:

1. How long will your engineer reach our factory?
Within one week after everything ready (machine arrival your factory, non-woven material, power source, air compressor etc. Prepared)

2. How many days will you finish installing?
We will finish installation and training within 15 days.

3. What should we charge for your engineer?
You should charge for the cost of our engineer's air tickets, hotel, food, and also their salary 80USD one day per person.

4. Does your engineer understand English?
Our engineers understand a little English. All our engineers have more than five years machine installation experience.

5.How could you do if the parts broken within warranty?
We would express the free replacement parts during the warranty date.
